Light painting is a technique where a shape is drawn with a light source while a camera is taking a very long exposure shot of it. To do this well by hand would take a lot of skill, so I naturally decided to make my “light art” with a CNC router.
Using this technique, the LED light is treated just like an engraving bit would be under normal circumstances. The difference is that the Y axis is swapped for the X axis allowing for easy movement in the plane that you see displayed in the picture above. This allows the old Y axis to switch the light on and off in the same way that an engraving bit is lifted to stop engraving and lowered to start (explained here). Instead of a bit though, it’s a switch.
Be sure to check out the video of the router in action (with the lights on) after the break:
If you’re curious about the router used, check out this [HAD] post. Also we have the [HAD] logo available in DXF format here if you’d like to use it in your own project. You may need to delete some layers depending on your use.
